Sportster S Specs: Harley-Davidson’s New Cruiser is Built to Perform Backed by Iconic Looks

Built on the Revolution Max platform, this may just be Harley's most enduring motorcycle yet.

When it comes to motorcycles, is there a name more iconic than that of Harley-Davidson? This may be a heritage brand from Milwaukee, Wisconsin, but they are still creating stylish and seemingly irresistible offerings. For 2021, one of their all-new bikes is the Sportster S, powered by the same engine that impressed critics and fans alike in the Pan America 1250 bike. Let’s closely examine what makes the 2021 Harley-Davidson Sportster S unique.

The Revolution Max 1250T Powertrain

2022 Harley-Davidson Sportster S 1250cc motor up close
2022 Harley-Davidson Sportster S
  • Power: 121 HP / 90 kW @ 7500 rpm
  • Engine Torque: 94 ft-lb (127 Nm) @ 6,000 rpm

This engine is a liquid-cooled V-Twin with double overhead cams and four valves with variable valve timing in each cylinder. What all this really means is that it’s one of the most cutting-edge and sophisticated engines that Harley-Davidson has ever put together. As we mentioned above, a version of this engine has been used in the past. Still, this one in the Sportster S has been adjusted to deliver far better low-end torque (94lb-ft overall rating) while still maintaining an impressive output of 121hp.

2022 Harley-Davidson Sportster S
2022 Sportster S. Photo: Harley-Davidson

Key performance specs:

SpecMetric
EngineRevolution Max 1250T
ValvesChain-driven, DOHC, hydraulic self-adjusting lifters, intake & exhaust VVT; four valves per cylinder
Bore4.13 in. (105 mm)
Stroke2.85 in. (72.3 mm)
Displacement76.4 cu in (1,252 cc)
Compression Ratio12.0:1
Fuel SystemElectronic Sequential Port Fuel Injection (ESPFI)
Exhaust2-into-1-into-2; catalyst in muffler

With riders finding a torque sweet spot between just 3,000 and 6,000rpm, the 227kg (about 500lbs) bike is perhaps surprisingly nippy, accelerating like a sports bike, while maintaining the charm of a classic cruiser. And if you’re new to cruiser bikes, here some great beginner models to consider. That brings us to the following particular point.

Iconic Looks

2022 Harley-Davidson Sportster S
2022 Sportster S. Photo: Harley-Davidson

This may be one of the most advanced bikes that Harley-Davidson has produced, but the company knows what its fans and others love in this brand, and that’s the same heritage looks that scream “Harley.” From the robust frame to the rider’s imposing cruising stance, from the black-finished hardware to the 48-type front wheel. There’s no mistaking this is pure Harley through and through.

Here’s a look at the dimensions:

Length89.2 in. (2,265 mm)
Overall Width33.2 in. (843 mm)
Overall Height42.9 in. (1,089 mm)
Seat Height, Laden28.9 in. (734 mm)
Seat Height, Unladen29.6 in. (753 mm)
Static Ground Clearance3.66 in. (93 mm)

A Harley Cruiser Built to Perform

black, gold, and maroon 2022 Harley-Davidson Sportster S rear view parked on street
2022 Sportster S. Photo: Harley-Davidson

Aside from the powertrain, the 2021 Sportster S benefits from Harley-Davidson’s latest drive technology. Featured most prominently are the Cornering Enhanced Drag-Torque Slip Control System, which reduces rear-wheel slip and locking from sudden downshifting, and the Cornering Enhanced Traction Control System, which prevents excess wheel spin while accelerating and uses four drive modes (Road, Sport, Rain, Custom) to optimize traction and account for leaning in lousy weather.

The suspension system is also a picture of modernity compared to past Sportster models. It features a rear single shock and front inverted forks, both adjustable. The engine and Sportster S chassis are bolted together as one, with the chassis stiffened by a welded tubular steel trellis swing arm with a stamped X-member.

Housing the Latest Technology

2021 Sportster S
2022 Sportster S. Photo: Harley-Davidson

The 2021 Sportster S may exude that more classic and traditional Harley-Davidson look, but it further stretches technological bounds through the happy inclusion of numerous other advanced features. First, the rider is treated to a 4-inch TFT screen with flawless contrast and readability. It offers a large digital speedometer surrounded by a tachometer, bike status, Bluetooth-powered infotainment and music, incoming call answering, and navigation. There’s also a tire pressure monitoring system on board.

2021 HD Sportster S Price and Release Date: Starting at $14,999

In USD, the 2021 Sportster S is set to start at $14,999 and will be available in the fall. It will also be available in Canada beginning at CA$19,999. Those who want to remain in the know should keep one eye on the Harley-Davidson press room and online showrooms. A new sporty age of Harley-Davidson is seemingly upon us.
